John Carter Learn how Kevin Hudson and his team at Double Negative used ZBrush to breathe life into the world of Barsoom.

Once the concepts were handed off, it was up to Kevin Hudson and his team at Double Negative to rebuild them as something that could actually be animated and rendered. This was far more than simply reworking the polygons in the concept models with a few new edge loops. In fact, Double Negative invented entirely new ways of creating displacement maps to simulate the interaction of muscles, veins and skin.

In our interview with Kevin we learn how ZBrush played an integral role to breathe life into the world of Barsoom!

I was recruited by Double Negative Visual Effects in London from Los Angeles to head up the modeling effort on this major Character piece. To date, it was the largest project they'd tackled. While in California, I first tried out ZBrush while working on Ghost Rider. I expanded its use to build the sixteen Zombie creatures for I Am Legend. I then used it to sculpt Dr. Manhattan for Watchman. But with over forty characters, John Carter was going to be the largest scale ZBrush character project that I'd ever attempted. It was also going to be Andrew Stanton's first foray into live action filmmaking, which meant we had to do an outstanding job.

My main role was taking the concept sculpts that came from Legacy Effects and expand upon them to create the production models and their corresponding displacement maps.

We had a Character Modeling team of about thirteen people. Some had a lot of background in character creation, while some had only worked in ZBrush a little bit and had to be brought up to speed. We had a couple of amazing character sculptors that brought their backgrounds to the project. Others brought a strong knowledge of anatomy that proved useful as we moved further into the project and began redesigning a lot of the anatomy of the characters. A solid knowledge of anatomy and a sculptor's eye are tantamount to success in this field. A couple artists had a good grasp of the character engineering aspects and helped in the ongoing development of the topology used in the characters.

My biggest goal was to take a group of people who hadn't worked that much in ZBrush, get them up to speed quickly. Then to create more characters than I'd ever attempted in a relatively compressed period of time. All for clients that hadn't ever done a live action film and an effects company that hadn't done this large a quantity of characters and therefore had a largely undeveloped character pipeline at that time.

We did four primary speaking characters, nine outrageous creatures, as well as a large number of secondary characters and variations.

The biggest challenge was the scope. There were so many characters to do that we needed to hit the ground running and get right into it. Luckily, I'd done a large number of zombie characters for I Am Legend, so I was used to taking a primary concept sculpt, extrapolating it out to large numbers of characters, and then maintaining them throughout a production. This was just going to prove to be larger and more challenging.

We received ZTools of character concept sculpts from Legacy Effects that had been developed with Andrew Stanton in California. We then took these and retopologized them in Maya using some basic Maya shrinkwrapping tools. I don't use anything tricky for my retopologizing, but use Maya's World Space Transfer Attributes tool to shrinkwrap my retopologized model onto the concept sculpt.

We then used ZBrush's Projection tools to extract as much data as possible from the initial concept sculpt. The model was then reposed into a more standard pose and we began resculpting with an eye for preserving as much of the concept sculpt's intentions as possible. Everyone would have a say at this point and often revisions to the anatomy to better serve rigging would be done.

The Environment team - headed by Guy Williams - also used ZBrush to touch up all the environments to give the stone a weathered and chipped look. They built intact structures, then used the Clipping brush to chip and flatten sections in order to make them appear old and broken. These chunks were then retoplogized before more subtle weathering was done.

I actually read the first book upon which the movie is based. When I was a kid, I was a huge E.R.B. fan and I spent one summer reading a lot of his Tarzan books. They were good fun pulp reading. I think the film owes a lot to some of the classic cover artwork used on the books, as the designs for the costumes are realizations of a lot of these covers.

We also made modifications to proportions based on animation tests using the basic model. All of this would lead us towards our final production models and sculpts.

ZBrush did a great job when reprojecting new topology onto our sculpts over the many generations of revisions throughout the show. I found that by taking the Blur setting down to 1 we preserved a lot of good detail. Andrew, who had spent a lot of time with Scott Patton at Legacy Effects, was very much in love with his characters and was always there to smack us if we varied too much from the original concept.

The costumes for the characters were modeled in Maya based on real-life costumes created by the production's Costume Designers. Surprisingly, the biggest challenge in the costumes was not the intricate leather pieces on the costumes, but rather the simple loincloth that the characters wore. It wasn't as clearly envisioned at the start of the production and was rebuilt numerous times over the course of the show. The "nappy" or "diaper-like" cloth was explored and reinvented numerous times.

Sculpting the character and building the initial topology is always only the beginning. After that initial build, the changes begin. At time, it is easy to get disheartened when everyone down stream from modeling begins making requests for changes.

Many of the characters have multiple limbs and this increased the amount of sculpting and retopologizing each time a change was requested.

Many of the characters also have these sizable tusks on their heads. At one point it was felt that it would be easiest to render these if they were separate pieces of geometry. The call was made to roll this approach out to the 35 or so characters that had this design element. Later we discovered that this assumption was unfortunately wrong. All these characters then needed to have a major overhaul to reincorporate the tusks back into the main body geometry and then reproject and touchup all the characters with this new base.

My favorite characters on the show were the Warhoons. They are these very primitive, hunchy, violent characters. They were the least developed of the concept sculpts and there needed to be a whole lot of them, so I had fairly free range to create a diverse range of variations for them. They are also some of the more outrageous characters in the film. We ran all of the Warhoon variation concepts past Andrew for approval. In the end I designed and modeled twelve Warhoon variations for the film. I also had the opportunity to help design the costumes for them based on production's concept of a bone costume.

The other character that was a fun challenge is the ten-legged Woola character. It looks and behaves a lot like a dog. As a dog owner myself, I attempted to put a little of my pug's facial details into the character model. Some of this was snuck in under the radar, so long as it didn't vary too far from the original concept from Andrew.

ZBrush's projection tools are great, but each time you reproject a little bit gets lost. It is a bit like making a fax of a fax of a fax. When detail is lost, it then needs to be recreated again.

Tars was the biggest challenge and a lot of modelers all had an impact on Tars. He is on screen a lot, and there was a lot of talk about the character looking like Willem Dafoe, or at least his essence. We did a lot of exploration on how much it should look like Willem Dafoe -- at one point we did a reworking of Tars to incorporate a lot of Willem Dafoe's facial characteristics. This was often refered to as the "Eleven" version. Ultimately, we backed off from this almost completely and returned to the original concept.

In the film industry, this process of coming back to the original concept isn't uncommon. Sometimes, the director needs to explore all the variations to confirm that the original inspiration was the best. Or at least, what they really wanted.

The White Apes were a technically challenging character because of their size and ZBrush poly count. I really took ZBrush to the limit and ultimately had to break the model up into separate UDIM pieces in order to export the displacement maps. For the most part, all of the characters were able to be exported using the Multi Map Exporter from ZBrush, but because of the high poly count on the Apes we couldn't do this. I used the Group UV tool to create separate groups for each of the UDIM tiles. I then then used the Groups Split tool to break the White Ape mesh up into separate SubTools. Even with splitting the model up, it was a challenge exporting the maps, as I maxed out the RAM on my machine.

The actual process was quite involved. The model had five levels of subdivision with at least three separate layers: Main, Skinless, and Vein.

We worked with three separate layers of displacement maps in order to get all of the displacements for each of the characters. The three layers consisted of Muscle, Veins and Skin Detail. We exported full displacement maps for each set.

The idea was to use masks to increase or decrease the the amplitude of the different muscles within the Muscle Layer displacement. The masks would, for example break out the bicep from the rest of the arm.

A special group, headed by Richard Clarke (who developed this technique for the show) would then increase the amplitude of the displacement to create the appearance of the muscle tightening. This meant that we built some very hyper-taught versions of the characters so that the displacements would appear very sinuous and tight.

For the Vein displacement, I would export a presmoothed Level 4 subdivision version of the character minus the veins. I would load the ZTool of the character, go to the highest subdivision level and make sure the Vein layer was on. I would then go down to Level 4, import the presmoothed Level 4 base and export the maps using this base. Because the Level 4 base did not have veins, and the level 5 had the veins, we would get a map where the only element that would appear in it would be the veins.

It was a complicated process and when I'd start on it I'd put on my headphones (without music) to minimize distractions and keep everyone away. This was especially true with the Apes, where I'd need to be swapping out my base model sections on a displacement by displacement basis. The Apes were by far the most complicated characters from which to export the maps.

I'm one of those crazy people who likes to tinker with things and find crazy workflows. This was far and away one of the craziest systems I've sorted out. I'm sure eventually, all this will be a simple button push.

ZBrush integrated very well with our other software. I found that the 32-bit maps gave me very good results in the displacement, especially in regards to micropolygons in Renderman. I've used it with applications that tessalate the model to achieve a resolution to displace, but micropolygons give me the closest thing to my original sculpt and seem to hold detail the best I've seen.

The projection tools in ZBrush for extracting detail from Concept sculpts continue to get better and better. The sculpting brushes continue to improve. I can't wait to start playing more with the auto retopologizing tools for creating concept sculpts, as this all looks revolutionary.

There is always room for improvement. I know I am always looking for ways that I can do my work more effectively and efficiently. ZBrush has become a vital tool in my work, both professionally and personally. I use it more and more these days and I am constantly looking for new ways to incorporate it into my workflow. I'm hoping at some point to try doing some Hard Surface modeling in it, as that would be a new challenge.

I think if we were to go back to Watchmen, I would love to use the Three Levels of Displacement trick for that. We did Dr. Manhattan with only the one displacement extraction and although it looks great, it doesn't give the incredibly organic look that can be achieved with three levels of displacement. However, Dr. Manhattan is ultimately a construct, and he is not organic. The sinuous effects achieved with the tri-level extraction might not prove appropriate for him.

Dr. Manhattan was certainly a fun character to build. The team that I was part of on that project was great and we were all fans of the subject. I loved doing all those zombies for I Am Legend, as I'm always attracted to fantastic, over-the-top, fun designs. I feel fortunate to have started in CG at a time when it was fairly new. It has been an incredible journey seeing the ongoing growth and developement. Anticipation for the new and exciting continues to excite me. I find myself still waking up looking forward to a new day helping to create imagery that hopefully inspires or at the very least entertains people.
